Max Spl: 137dB
Nominal Beamwidth: 90° Conical, Vertically Asymmetric (+40, -50)
Lf Transducer, Loading: 15in Cone, 3in Voice Coil, Vented
Hf Transducer, Loading: 1.4in Exit, 3 in voice coil neodymium compression driver, Linear Conical Waveguide
Signal Processing: DSP with EAW Focusing and DynO
Modes: Main / Monitor, Mic/Line
Input Type: Electronically Balanced XLR / TRS
Loop Type: Electronically Balanced XLR
Amplifier Type: Class D
Max Output Lf / Hf (peak): 1500W
Ac Mains (nominal):
Connector Neutrik PowerCON®
Input 100-120V or 200-240V, 50-60Hz
Material: Acoustically Enhanced Polypropylene
Dimensions (h × W × D): 27.6 x 17.3 x 16.9in (700 x 440 x 430mm)
Net Weight: 58lb (26.4kg)
Shipping Weight (approx): 66lb (30kg)
