Max Spl: 135dB
Nominal Beamwidth: 90° Conical, Vertically Asymmetric (+40, -50)
Lf Transducer, Loading: 12in Cone, Vented
Hf Transducer, Loading: 1in Exit, 1.4in voice coil compression driver, Linear Conical Waveguide
Signal Processing: DSP with EAW Focusing and DynO
Modes: Main / Monitor, Mic/Line
Input Type: Electronically Balanced XLR / TRS
Loop Type: Electronically Balanced XLR
Amplifier Type: Class D
Max Output Lf / Hf (peak): 1500W
Ac Mains (nominal):
IEC Connector
Input 100-120V or 200-240V, 50-60Hz
Material: Acoustically Enhanced Polypropylene
Dimensions (h × W × D): 25.2 x 15 x 14.4in (640 x 380 x 365mm)
Net Weight: 43lb (19.5kg)
Shipping Weight (approx): 50lb (23kg)
